Siemens 6GK1901-1BB10-2AA0 IE FC RJ45 Plug 180 (2×2) (6GK1901-1BB10-2AA0) CAN Electric — Industrial Automation Parts Supplier

A field-terminable FastConnect RJ45 plug

The 6GK1901-1BB10-2AA0 is the SIMATIC NET Industrial Ethernet FastConnect RJ45 plug 180 (2×2). It terminates the four wires of an IE FC TP cable 2×2 with integrated cut-and-clamp contacts — no crimp tool, no solder, no shielding-braid prep — so an engineer builds a rugged, shielded RJ45 drop in seconds on site.

Rugged, IP20, reusable

A rugged metal enclosure (IP20) with a 180° cable outlet keeps the cable running straight out of the port. The connector is silicon-free, supports PoE / PoE+, and can be opened and re-terminated up to 10 times for maintenance rework.

Part of the SIMATIC NET FastConnect family

It is the standard way to build PROFINET / Industrial Ethernet field wiring on IE FC TP cables, mating to standard RJ45 ports on PROFINET controllers, switches, I/O and HMI panels.

Data per the Siemens Industry Mall entry and the official 6GK1901-1BB10-2AA0 data sheet; confirm the current data sheet before ordering large quantities.

Tool-free FastConnect termination

Integrated cut-and-clamp contacts terminate the 4 wires of an IE FC TP cable 2×2 (AWG22) without crimp or solder tools, cutting installation time to seconds per end — ideal for on-site PROFINET wiring.

Rugged and reusable

A rugged metal enclosure protects the joint in panels and cabinets, and the plug re-terminates up to 10 times, so a drop can be re-dressed or re-cabled during maintenance without replacing the whole assembly.

Built for industrial Ethernet drops

Rated 10/100 Mbit/s with Cat5 structured cabling, IP20 and PoE / PoE+ support, it suits PROFINET drops to switches, controllers, I/O and HMI across the factory floor.

Pick by transfer rate and cable outlet: the 6GK1901-1BB10-2AA0 on this page is the standard 10/100 Mbit/s 180° plug for IE FC TP cable 2×2 (AWG22); the -1BB20 90° version suits tight panels where the cable must exit at an angle; the -1BB12 4×2 version is CAT6A rated for 10/100/1000/10000 Mbit/s drops on IE FC TP cable 4×2 (AWG24).

PROFINET device drops

Terminated onto an IE FC TP cable 2×2, it makes the shielded RJ45 drop from a PROFINET controller, switch or field device; the 180° outlet keeps the cable running straight out to simplify routing in trays and panels.

Field cabling and rework

Tool-free termination and 10-times reusability suit both new builds and maintenance — a damaged drop can be re-terminated on site in minutes without replacing the whole cable.

Industrial Ethernet and HMI connectivity

It connects switches, controllers and HMI panels in cabinets and on machines, the same role as the HMI hardware in the Related Siemens HMI Products block below.

Condition stated in writing

We are an independent channel trader, not Siemens and not a factory-authorized distributor. Every unit supplied is genuine new, and that condition is written on every quote.

Stock you can plan a project around

We trade a broad Siemens FastConnect and SIMATIC inventory; the Related Siemens list on this page shows live USD list prices with EXW Hong Kong terms, and each quote states the exact quantity available.

Export handled on one thread

Cross-border requests are routine: a single thread covers quote, compliance note and dispatch, so buyers in India, Egypt, the Netherlands, Thailand, Malaysia, the Middle East and South America deal with one team.

The 6GK1901-1BB10-2AA0 terminates an IE FC TP cable 2×2 (for example IE FC TP Standard Cable GP 2×2, AWG22) with the FastConnect cut-and-clamp system and mates to any standard shielded RJ45 port on PROFINET controllers, switches, I/O and HMI. No special engineering is required beyond correct wire assignment for 10/100 Mbit/s.

• Email sales@can-electric.com with the order number 6GK1901-1BB10-2AA0, quantity, delivery country, and whether you also need the IE FC TP cable 2×2 or strain relief.
• Prices are in USD, shipped from Hong Kong by DHL under EXW terms; units from current stock ship factory-sealed.
• Need matched IE FC TP cable or other FastConnect plugs? Ask for them on the same request.
