SIMATIC HMI TP700 Comfort 7-inch Touch Panel PROFINET and PROFIBUS (6AV2124-0GC01-0AX0) CAN Electric — Industrial Automation Parts Supplier

What is 6AV2124-0GC01-0AX0?

It is the SIMATIC HMI TP700 Comfort 7-inch Touch Panel PROFINET and PROFIBUS — a 7-inch widescreen TFT Comfort Panel with analog-resistive touch operation, both PROFINET and MPI/PROFIBUS DP interfaces, 12 MB user memory and Windows CE 6.0, engineered in the TIA Portal with WinCC Comfort V11 or higher.

Is this panel discontinued?

Siemens lists it as PM400 — product phase-out announced since 31 January 2026. It is not yet fully discontinued and can still be sourced, but for new machine designs Siemens names 6AV2128-3GB06-0AX1 as the successor. We confirm current availability per order and do not quote stock we cannot supply.

Does it have PROFINET and PROFIBUS?

Both. It has one PROFINET / Industrial Ethernet port with an integrated 2-port switch and one MPI/PROFIBUS DP (RS-485) interface, so the same panel can be used on either network.

Which software do I need to configure it?

The TIA Portal with WinCC Comfort V11 or higher. Comfort Panels are not configured with WinCC Basic (Basic Panels) or WinCC Unified Basic (Unified Basic Panels).

Does it have physical function keys?

No. Operation is purely via the analog-resistive touch screen; the panel has no physical function keys.

How many colors does the display show?

16,777,216 colors (16.7 million) at a resolution of 800 × 480 pixels.

What display does it have?

A 7-inch widescreen TFT with 800 × 480 pixels and dimmable LED backlighting (MTBF 80,000 h at 25 °C).

Which PLCs can it connect to?

Over PROFINET, MPI or PROFIBUS DP it couples to SIMATIC S7-1200, S7-1500 and S7-300/400 controllers, and it also supports Modbus TCP/IP and EtherNet/IP.

Does it support SD cards and USB?

Yes — two SD card slots for archiving and project storage, two USB 2.0 host ports and one USB Mini-B port for project transfer and peripherals.

What power supply does it need?

24 V DC with a permissible range of 19.2 – 28.8 V DC, rated current 0.5 A and typical power input of about 12 W.

Is it suitable for harsh environments?

The front is an aluminium die-cast panel rated IP65 (dust and water jet resistant); the rear is IP20. Operating temperature is 0 °C to +50 °C.

Is the panel genuine and new?

We supply genuine Siemens hardware sourced through established channels. Condition (new, new-surplus or refurbished) is stated on every quote, and units are inspected before dispatch.

Is CAN Electric an authorized Siemens distributor?

No — we are an independent channel trader, not Siemens. We source genuine Siemens products through Siemens-authorized distribution partners and confirm condition and delivery on your quote.

How do I get a quote and how is it shipped?

Email sales@can-electric.com with the order number, the condition you need and the delivery country. We confirm availability and terms per order and quote in USD; shipment is from Hong Kong via DHL worldwide, with packaging and lead time confirmed on each quote.
