In large-scale industrial control, mismatched analog input module parameters (insufficient channels, low accuracy, large sync error) often cause monitoring failures and quality deviations. Need a 1769-IF16C analog input module perfectly parameter-matched for Rockwell 1769 series, meeting multi-channel, high-precision synchronous acquisition demands?
✅ Parameter-Matched for Rockwell 1769 Series
Tailored for Rockwell 1769 series, 1769-IF16C features full parameter compatibility. Its communication and power parameters align perfectly with 1769 controllers, enabling plug-and-play without extra configuration, avoiding sync issues and system conflicts.
✅ 16-Channel Parameter: Large-Scale Monitoring Ready
16 independent analog input channels (core parameter for large-scale monitoring) enable simultaneous connection of 16 sensors (temp, pressure, flow). Compared to 4 sets of 4-channel modules, it reduces costs and avoids inter-module parameter inconsistency.
✅ High-Precision & Sync: Reliable Data Acquisition
Core performance parameters: ±0.1% full-scale conversion accuracy (minimizes signal error) and <1ms inter-channel sync error (ensures simultaneous data capture). 200 samples/s per channel enables real-time dynamic signal acquisition without delay.
✅ Anti-Interference & Temp: Adapt to Harsh Scenarios
Environmental parameters: EN 55011 Class A anti-interference (stable operation near frequency converters/motors) and -40°C to 70°C operating temp (adapts to low-temp workshops and high-heat areas), ensuring parameter stability in harsh conditions.
✅ Core Technical Parameters of 1769-IF16C
- Model: 1769-IF16C (Exclusive for Rockwell 1769 series)
- Input Signal: 4-20mA / 0-10V (Compatible with standard industrial sensors)
- Channels: 16 Independent Inputs (Large-scale multi-point monitoring)
- Conversion Accuracy: ±0.1% Full Scale (High-precision control)
- Sync Error: <1ms (Consistent multi-point data)
- Sampling Rate: 200 Samples/s per Channel (Real-time dynamic capture)
- Anti-Interference: EN 55011 Class A (Stable in high-noise environments)
- Operating Temp: -40°C to 70°C (Extreme condition adaptation)
- Certifications: CE, UL, RoHS (EU/US industrial standards)
- Installation: ≤15 Mins (Plug-and-play, no professional programming)
✅ Case: Parameter Advantages Resolve Production Pain Points
A European auto parts maker faced 1769 system issues: insufficient channels (8 channels, unable to cover 12 monitoring points) and large sync error (>5ms). After switching to 1769-IF16C, its 16-channel and ≤0.8ms sync parameters solved the problems; ±0.1% accuracy reduced acquisition error. Production waste rate dropped from 9% to 2.3%, saving €55,000/month—driven by 1769-IF16C’s parameter performance.
✅ Strict Parameter Calibration & Certifications
Each 1769-IF16C undergoes 100-hour continuous operation testing and 15 environmental tests to verify parameter stability. CE/UL/RoHS certified, all technical parameters meet EU/US standards for reliable use.
✅ User-Friendly Design Lowers Maintenance Cost
Auxiliary advantages: ≤15-minute installation (plug-and-play), independent channel indicators (quick fault location), and built-in self-diagnosis (automatic parameter deviation detection), reducing maintenance difficulty and costs.
✅ 3 Steps to Get 1769-IF16C Parameter Solutions
Share your 1769 configuration and parameter needs; get customized matching solutions; confirm order for door-to-door delivery and parameter debugging guidance. Efficient and transparent.
✅ Contact for Detailed Parameter Documents
For 1769-IF16C technical parameter sheets, calibration reports and exclusive quotes, email: allen@can-electric.com. Mention this article for 30-day limited discount! Professional team provides one-on-one parameter guidance, reply within 24hrs.
